The Fly Wheel provides the necessary inertia to carry the engines pistons through the stroke of the cycle. The teeth that surround the Fly Wheel used by the starter to turn the engine over till it starts up, then the teeth eventually become worn over time. The hardest part in this process is is just trying to acessing it. You will need a wrench, drip pan, flare nut wrench, tranny jack and tranny fluid. First step it removing the drive shaft from the back of the tranny. How you do this is, disconnect the drive shaft from the differential. The driveshaft attaches to the differential with two bolts, which are in the shape of a "u" know as the u joint. Each bolt has a single nut on both ends. You are going to need to remove these with a wrench.
Next pull the driveshaft away from the differential, now put the drip pan under the back of the tranny were the driveshaft enters. Pull driveshaft towards back of car in order to remove. Let all fluid drain.
Second, Disconnect the speedometer cable, shift linkage, and tranny cooler lines from the transmission. These three components need to be disconnected with a wrench. The cooler lines need to be disconnected with the flare-nut wrench to avoid damage. Third, Put the jack under the drain lift jack until secure under tranny oil pan. Fourth,disconnect tranny from engine. Take off the four remaining nuts used to attach the trannys torque converter to the back of the flywheel from under the car using a wrench. Disconnect retaining bolts used to attach trannys engine block with a wrench. Fifth, Remove trannys cross member, this holds the tranny to the cars frame. Now pull tranny toward rear of car to reveal the flywheel.
Remove flywheels retaining bolts located in the center of the flywheel with wrench. Pull the flywheel off of the crankshaft, position the new flywheel against the back of the crankshaft. Then install and tighten the bolts taken out with a wrench. Sixth, attach the tranny back to the engine. Sliding the trannys against the back of the engine with trannys jack. Make sure that the suds on the torque align with the holes on the flywheel. Install and tighten torque converter with the nuts you took out and again using the wrench to do this. Install the trannys bolts through the front of bellhousing and into the back of the engine, tighten bolts with wrench. Seventh, Install trannys cross member onto the cars frame. Connect the two cooler lines to the tranny with the flare-nut wrench. Also connect the speedometer and shift linkage to tranny with wrench.
Eighth, pu the driveshaft back in the tranny by sliding it in the back of tranny. Position the rear of the driveshaft against the differential. Lastly install and tighten the four nuts into the two "u" bolts with a wrench. Add transmission fluid into the dipdtick. YOURE DONE !!!
Tuesday, December 17, 2013
Thursday, December 12, 2013
Pros and cons of Chevrolet Camaro
Well give them the benefit of the doubt and start with the pros. This car has the standard V6 which carries 323 horse power this gets 30 miles to the gallon including 278 lbs ft of torque. Next there is the V8 which carries 426 you can also get the SS(super sport.) Lastly the Z28 which by the way was originally introduced in 1967, the hand assembled LS7 that has 505 hp and 481 lb ft torque. This has something very cool though i have to admit, called TREMEC or TR6060. This is a six speed manual gear box that has a close ratio gearing that ensures quick and precise shifting. Now that cons. I did a little researching on this car and i read that this car had poor visibility, heavy weight which makes twisty turns difficult to handle. Not enough head room for the tall glasses of water out there that just want to go fast. Not to mention that this car looks nothing the the original and does not deserve the name Chevrolet Camaro. Starting from the front of the vehicle, The front fender looks like it got ripped of the 2009 or 2010 Ford Mustang.
Except they made the front of this car almost come to a point. Theres nothing muscle about that. The hood scoop is all wrong it looks like a bubble. Next the fenders are terrible. The whole line of the car is way off of the original.
Have you ever seen a 2010 Chevrolet Corvette ? Not saying the air vents are only on this year but yea they stole the air vent idea but instead they decided to flip it and put them in front of the back fender. The mirrors are ridiculous by the way. This car may kick ass when it comes to performance but model wise damn its ugly and does not deserve the name Camaro.
Except they made the front of this car almost come to a point. Theres nothing muscle about that. The hood scoop is all wrong it looks like a bubble. Next the fenders are terrible. The whole line of the car is way off of the original.
Have you ever seen a 2010 Chevrolet Corvette ? Not saying the air vents are only on this year but yea they stole the air vent idea but instead they decided to flip it and put them in front of the back fender. The mirrors are ridiculous by the way. This car may kick ass when it comes to performance but model wise damn its ugly and does not deserve the name Camaro.
Sunday, December 8, 2013
How to change your windshiled wiper motor
First step, unplug power connection located in main fuse box if you cant find this then the owners manual will have a diagram. Turn your windsheild wiper position on. Test and check for power, ground at the motor(negitive). Disconnect the wiper arm assembly from the motor. Disconnect wiring harness at the motor. Remove the wiper motor mounting bolts and motor. Now replacing old motor with the new one. Put back in the bolts you had taken out. Torque to the manufacturers specifications. Connect the electrical harness. Re-connect the negitive battery cable. Lastley check your work and make sureeveything is either screwed or plugged in. Test them out !
